                              Go or No go that is the Question



                                 t seems like a military operation waiting the D day’s coming for the whole industry to
                                 be devoted to a brand new era. We do believe there is no main technical blockage on the
                              Iway to create this new world. It is true that all kind of materials and methodologies are
                              almost ready sine both 300mm and 450mm processes share with the same technology node.
                              Therefore, more die-cost saving will finally become the fatal weapon to win the survival.
                              For sure, an oligopoly in tool demand side makes tool supply side become hesitated due to
                              the concerns of tool market in total quantity. In this article, some analyses might give a hint
                              whether the “operation” should be Go or No go.



                              Physical Limitations from the Earth



                                     aydreamers always think where is the best location for human beings to extend
                                     the wafer size perfectly with the lowest cost. The answer might be the Moon since
                              Dthere is only 1/6 of the Earth’s gravity to prepare colossal size silicon ingot without
                              concerns from the sag in the wafer center. Si wafer thickness can be shrunk to the thinnest
                              level, which means wafer intrinsic cost could be much lower. Besides, heavy tool parts
                              can be easily handled manually without sophisticated design assistant tools like lifters or
                              cranes. Furthermore, it is also possible to get bigger lens size to improve the throughput of
                              photography tools.
                              A vacuum environment in the Moon also benefits to grasp eUV (Extreme ultraviolet) from
                              the Sun without concerning power consumption for the extremely high power laser source.
                              The vacuum environment can also help to avoid extra oxidation as wafers transferred to the
                              next process step. Due to less weight in the Moon, less cooling capacity can be gained from
                              the lithography exposure stage for air floating or magnetic floating movement.

                              Return to the Earth and back to the real world, the industry encounters so many challenges
                              not just coming from gravity. Therefore, plenty of innovations are necessary to put 450mm era
                              into practice.



                              Discovery of New Markets and Demands




                                    irst of all, what are the expectations from this industry upon 450mm era? Of course,
                                    economic factor is the most fundamental consideration for more production output
                              Fwith more die cost saving. Tool supplier side also gives hope upon the new market
                              demand from not only mobile demands but also from human health caring demands. In
                              2012, MIT (Massachusetts Institute of Technology) has announced a novel glucose fuel
                              cell, development work granted by NIH (National Institute of Health) and Office of Naval
                              Research, which is manufactured by semiconductor process, to utilize blood sugar to
