           水處理系統桶槽洩漏之分析與防治

           Analysis and Prevention of Tank Leakage of Water Treatment System




                                                                                       文│莊仲霆 張峻嘉│台南廠務三部│


           摘要 / Abstract

              不論化學品的儲存桶槽或是運轉系統桶槽，一旦發生損壞則會影響整個系統的操作更可能影響人身安全。F14P12遭遇多次
           桶槽洩漏事件，為了瞭解其真正洩漏原因，進而收集F14A(F6、F14P12、F14P34)廠區內桶槽出現的洩漏情況，歸納出失效模式並
           統整可能造成桶槽洩漏的真因。
              在此次的研究統計中，桶槽的內外部設計與材質的選擇，對於桶槽的使用年限有著非常大的影響，另外FRP(fiber-reinforced
           plastic；玻璃纖維強化塑膠)桶槽正確的施作與修補手法對於桶槽有延續使用壽命的效果，文章中將利用檢驗工具針對CS(Carbon
           Steel )+rubber lining桶槽的製作與修補進行驗證與測試，建立補強方式、正確施工手法以及檢驗準則，如此一來可大幅降低桶
           槽洩漏之突發狀況，因此，就能從事後補救的方式轉變至事前的預防。

           關鍵詞 / 桶槽洩漏、玻璃纖維強化塑膠、CS+rubber lining桶槽

              Any damage of chemical storage tank and operation system tank will affect the operation of the entire system and
           even personal safety. To identify the root cause of tank leakage, we collect the leakage cases of F14A(F6, F14P12 and
           F14P34) and investigate via FMEA(Failure Mode and Effects Analysis).
              According to our study, it's found that the design of the tank and the choice of material have a significant effect
           on the duration of service. For FRP(fiber-reinforced plastic) tank, it's found that a proper construction method and
           refurbishment are helpful on extending the duration of service. For CS(Carbon Steel) and rubber lining tank, we tested
           and verified that the occurrence of tank leakage could be reduced by inspection tool if the tank were installed with
           a proper construction method or refurbishment. In addition, we also establish the guidelines of refurbishment and
           construction methods for CS and rubber lining tanks. As a result, we can take preventive measures against the sudden
           tank leakage which could only be solved by remedial action.

           Keywords / Tank leakage, fiber-reinforced plastic(FRP), CS+rubber lining tank



           1.  前言

              桶槽的製作工法與設計，往往影響桶槽使用年限的多                        及實際狀況，後續發現大部分的桶槽洩漏原因重複性高，所以
           寡。若有缺陷，桶槽在使用下可能出現洩漏情況，一旦發生則                       針對常造成桶槽洩漏的原因進行失效分析，並找出方法補救與
           必須耗費許多人力、時間與金錢進行補救，如果桶槽內部填裝                       防治，達到降低桶槽洩漏再發生機會，並了解桶槽製作過程中
           化學品，更有影響人身安全的疑慮，故桶槽的健全與否將影響                       可能造成使用時洩漏之因素。          [04]
           系統的運轉與人員安全。
              為了解F14A(F6、F14P12、F14P34)廠區內桶槽出現的洩漏
           情況，故統整分析各廠桶槽洩漏的系統、洩漏位置、損壞率以
